𝗙𝗢𝗥 𝗬𝗢𝗨𝗥 𝗕𝗜𝗚, 𝗦𝗧𝗨𝗣𝗜𝗗 𝗥𝗜𝗗𝗘𝗦
On the fringes of cycling and triathlon, already endurance-oriented sports, there are athletes pushing their bodies and equipment to the limit. Ultra-distance, but ultra-fast. We call these Big, Stupid Rides, and since the introduction of the Caledonia in 2020, athletes around the world have been exploring just how big and just how stupid those rides can be. These athletes reach for the Caledonia-5. It’s built to handle long-distance, high-speed racing—with fit and handling geared toward comfort, but without sacrificing the Cervelo race bike feeling.
For the new Caledonia-5, we focused on improvements that would be meaningful for the people pushing it to its limits. The biggest thing you’ll notice is the addition of the in-frame storage first seen on P-Series. This isn’t designed to fit a burrito—there’s only room for a small multi-tool, tube, and a CO2 canister. Then we looked to comfort: The seat stays are dropped, similar to Aspero, which makes that rear triangle more acute, and more vertically flexible. At the same time, there’s a bit more downtube stiffness to maintain that pro-level responsiveness Caledonia is known for. You can still stuff some big tires (36mm) in there, and every bike comes with fender mounts.
Like all Cervélos, Caledonia-5 is UCI approved, and carries a lifetime warranty. We make race bikes, and we make them to last.
𝗜𝗡-𝗙𝗥𝗔𝗠𝗘 𝗦𝗧𝗢𝗥𝗔𝗚𝗘
New this year on the Caledonia-5, the in-frame storage is designed for a tube, small multi-tool, and a CO2 canister. Out of sight, out of mind, until your tire makes the bad noise.The hatch is easily removable even with gloves on—just flip the lock and pull.
𝗔𝗘𝗥𝗢𝗗𝗬𝗡𝗔𝗠𝗜𝗖𝗦
All Cervélo bikes are aero bikes. And when you’re on three days of panini and candy, running on fumes into Checkpoint One, you’ll appreciate the free speed. The completely internal housing and aero tube shapes team up to help you do battle against the wind.
𝗥𝗘𝗙𝗜𝗡𝗘 𝗔𝗡𝗗 𝗘𝗡𝗛𝗔𝗡𝗖𝗘
Caledonia-5 is meant for all-day riding, high-pace group rides, and routes featuring less-than-ideal tarmac.We kept all the good stuff, but made some key improvements. The bearing caps are now split so you can swap between the high and low bearing cap without bleeding the brakes if you need to make a fit change.
𝗛𝗔𝗠𝗠𝗘𝗥𝗛𝗘𝗔𝗗-𝗘𝗤𝗨𝗜𝗣𝗣𝗘𝗗
The Red AXS build comes with the all-new Hammerhead Karoo. The Karoo is the perfect companion for big stupid rides, and allows you to pick your preferred route surface (road, gravel) as you explore the limits of a “good idea.”
𝗥𝗘𝗦𝗘𝗥𝗩𝗘 𝟰𝟮|𝟰𝟵
Developed and tested using Turbulent Aero technology, the 42|49 is designed for everything you do, providing all-day capability with aerodynamic sensibilities. Raced at events as varied as the Paris-Roubaix and the Giro D’Italia, the 42|49 wheels have a lifetime warranty supported by a no-fault crash replacement.
|
48 |
51 |
54 |
56 |
58 |
61 |
Reach | mm
|
360 |
369 |
378 |
387 |
396 |
405 |
Stack | mm
|
505 |
530 |
555 |
580 |
605 |
630 |
Head Tube Angle
|
70.5° |
71.5° |
72° |
72° |
72° |
72° |
Front Center | mm
|
580.5 |
582.7 |
592.5 |
609.5 |
627 |
644.1 |
Bottom Bracket Drop | mm
|
76.5 |
76.5 |
74 |
74 |
71.5 |
71.5 |
Head Tube Length | mm
|
89.5 |
110.3 |
136.3 |
162.6 |
191.5 |
217.8 |
Top Tube Length | mm
|
502 |
522 |
543 |
565 |
581 |
598 |
Seat Tube Angle
|
74.5° |
74° |
73.5° |
73° |
73° |
73° |
Standover Height | mm
|
701 |
743 |
775 |
798 |
824 |
847 |
Trail | mm
|
57.8 |
57.8 |
57.8 |
57.8 |
57.8 |
57.8 |
Wheel Size
|
700C |
700C |
700C |
700C |
700C |
700C |
Fork Offset | mm
|
60 |
54 |
51 |
51 |
51 |
51 |
Wheelbase | mm
|
983.3 |
985.6 |
996.3 |
1013.4 |
1031.8 |
1048.9 |
Chainstay Length | mm
|
415 |
415 |
415 |
415 |
415 |
415 |
Not sure if we have your size? Give us a call or shoot us an email — we’re happy to help you find the perfect fit!
