When we first premiered the Factor O2, it was ridden to mountain top stage victories at the Tour de France and second place at Paris-Roubaix. As good as that version of the O2 proved to be, this revamped O2 is even better, thanks largely to improved manufacturing techniques that allow us to make the frame lighter, stronger, and more durable. Our ability to control every aspect of the manufacturing process allows us to optimize every aspect of the frame design. Advancements like the Svelte Fork increase control, stiffness, and comfort, while the tapered steerer tube enhances steering precision and introduces aerodynamic gains.
๐ ๐ฎ๐ป๐๐ณ๐ฎ๐ฐ๐๐๐ฟ๐ถ๐ป๐ด ๐๐
๐ฝ๐ฒ๐ฟ๐๐ถ๐๐ฒ
Always looking for innovative ways to make our bikes even better, we have used ultra high pressure molds when manufacturing the O2 frames. These molds remove excessive resin from the base material, which not only helps to keep the weight to a minimum, but also ensures a stronger, more efficient carbon frame. Itโs an innovative engineering solution that translates directly into performance. This advanced manufacturing method allows us to create a stiff, responsive frame that also is comfortable enough for Paris-Roubaix cobbles and stable enough at high speeds to slice down an alpine descent.
๐จ๐ป๐ฐ๐ผ๐บ๐ฝ๐ฟ๐ผ๐บ๐ถ๐๐ฒ๐ฑ ๐ฅ๐ถ๐ด๐ถ๐ฑ๐ถ๐๐
The asymmetrical downtube forms the backbone of the frame, with the carbon layup focused on withstanding the various torsional forces each side of the bike will experience. The bottom bracket shares this asymmetric design to ensure the drive train side stands up to a WorldTour level power output. The rear triangle works to ensure solid acceleration through the drivetrain thanks largely to the beefy chainstays. The lithe seatstays introduce a comfortable level of vibration absorption without compromising the efficiency of power transfer.
๐๐ผ๐ป๐ณ๐ถ๐ฑ๐ฒ๐ป๐ฐ๐ฒ, ๐๐ผ๐ป๐๐ฟ๐ผ๐น ๐ฎ๐ป๐ฑ ๐๐ผ๐บ๐ณ๐ผ๐ฟ๐
The geometry is specifically optimized for consistent handling across all sizes ensuring stability and effective power transfer.
๐๐๐๐บ๐บ๐ฒ๐๐ฟ๐ถ๐ฐ๐ฎ๐น ๐๐ผ๐๐ป๐๐๐ฏ๐ฒ
This serves as the backbone of the frame connecting the headtube to the bottom bracket. O2โs asymmetrical downtube provides a perfect balance of torsional and vertical stiffness and is largely responsible for the highly reactive and lively nature of the bike.
๐ฃ๐ผ๐๐ฒ๐ฟ ๐๐ฟ๐ถ๐๐ฒ๐๐ฟ๐ฎ๐ถ๐ป
At the core of the Power Drivetrain sits the asymmetric bottom bracket, the design of which facilitates a smooth yet stiff transition between the asymmetric downtube and the tall chainstays. The continuous downtube-to-chainstay structure of the O2 frame provides exceptional stiffness for minimum energy loss and maximum acceleration.
๐ฆ๐๐ฒ๐น๐๐ฒ ๐๐ผ๐ฟ๐ธ
Numerous layups and endless hours spent perfecting the design, every element of O2โs Svelte Fork focuses on the ultimate goal of increased control, stiffness, and comfort. Precise and light, the Svelte Fork uses a tapered steerer tube for increased steering precision and aerodynamic gains.
๐ฆ๐น๐ฒ๐ฒ๐ธ ๐๐ป๐๐ฒ๐ฟ๐ป๐ฎ๐น ๐๐ฎ๐ฏ๐น๐ฒ ๐ฅ๐ผ๐๐๐ถ๐ป๐ด
The internal routing for the O2 series accommodates both electronic and mechanical shifting. Our design solutions all the system to remain mechanic-friendly and lightweight.
๐ช๐ถ๐ฑ๐ฒ ๐ฆ๐๐ฎ๐ป๐ฐ๐ฒ ๐ฆ๐ฒ๐ฎ๐ ๐ฆ๐๐ฎ๐๐
Wide stance seat stays help with lateral stiffness in the rear triangle while keeping the seat stays thin for compliance and comfort.
๐ง๐ถ๐ฟ๐ฒ ๐ฐ๐น๐ฒ๐ฎ๐ฟ๐ฎ๐ป๐ฐ๐ฒ ๐ผ๐ณ ๐๐ฝ ๐๐ผ ๐ฏ๐ฌ๐บ๐บ ๐๐ถ๐ฑ๐ฒ
Having the ability to run wide tires on this racing bike offers the rider greater choice and improved comfort.
Frame | Torayยฎ, Nippon Graphiteยฎ Pan-Based Fiber |
Fork | Factor O2 VAM Svelte / Svelte Disc |
Seatpost | 27.2 Round, post not included |
Barstem | Black Inc Integrated Barstem Reach 80mm, drop 120mm. Multiple stem lengths and bar widths available |
Headset | FSA 1-1/8โณ upper and 1-3/8โณ lower bearings |
Head Tube Diameter | 1-1/8โณ upper and 1-3/8โณ lower |
Saddle Rail Clamps | 7x7 and 7x9 |
Bottom Bracket | T47A |
Cable Routing | Internal |
Compatible Components | Electronic |
Brake type | Disc |
Max Rotor Size | 160mm front & rear |
Max Chainring | 54-tooth |
Front Axle | 12 x 100mm thru-axle |
Rear Axle | 12 x 142mm thru-axle |
Wheelset | Black Inc 28|33 |
Wheel Size | 700c |
Max Tire Clearance | 30mm |
Weight | 885g |
Manufacturer Warranty | Limited Lifetime Warranty |
ย
Size | 49 | 52 | 54 | 56 | 58 | ||
---|---|---|---|---|---|---|---|
Aย Stack | 503 | 523 | 542 | 565 | 587 | ||
Bย Reach | 370 | 376 | 384 | 392 | 401 | ||
Cย Head Tube Angle | 71.3ยฐ | 71.6ยฐ | 73.1ยฐ | 73.3ยฐ | 73.3ยฐ | ||
Dย BB Drop | 75 | 70 | 70 | 70 | 70 | ||
Eย Trail | 60 | 58 | 59 | 58 | 58 | ||
Fย Fork Rake/Offset | 53 | 53 | 43 | 43 | 43 | ||
Gย Chainstay Length | 406 | 406 | 406 | 406 | 410 | ||
Hย Wheelbase | 970 | 982 | 972 | 985 | 1005 | ||
Iย Bike Standover Height | 727 | 750 | 772 | 794 | 820 | ||
Jย Seat Tube Length | 455 | 480 | 503 | 526 | 548 | ||
Kย Seat Tube Angle | 74ยฐ | 73ยฐ | 73ยฐ | 73ยฐ | 73ยฐ |
Not sure if we have your size? Give us a call or shoot us an email โ weโre happy to help you find the perfect fit!
